FDY Polyester Yarn | Technical Data & Specs for Fishing Net, Shoe & Industrial Use
1. Technical Specifications
| Parameter | Specification | Tolerance | Test Method |
|---|---|---|---|
| Material Composition | 100% Virgin Polyester (PET) | 100% | FTIR Analysis |
| Yarn Type | FDY (Fully Drawn Yarn) | - | Visual/Process |
| Tenacity (Strength) | 6.8 - 8.0 g/den | ± 0.2 | ASTM D2256 |
| Elongation at Break | 15% - 22% (Adjustable by denier) | ± 2% | ASTM D2256 |
| Hot Air Shrinkage | ≤ 7% @ 177°C | ± 1% | ASTM D5104 |
| Denier Range Available | 500D, 1000D, 1500D, 2000D, 2500D, 3000D | ± 3% | ASTM D1907 |
| Twist Level (TPM) | 80 - 400 TPM (Z or S twist, Single or Ply) | ± 5% | ASTM D1422 |
| Moisture Regain | 0.4% (Standard condition) | - | ASTM D2654 |
Available Grades by Application
Please select the appropriate grade based on your manufacturing requirements
NO. |
ITEM |
UNIT |
840D/1 |
840D/2 |
1260D/2 |
1260D/3 |
1680D/2 |
1890D/2 |
|
(930dtex/1) |
(930dtex/2) |
(1400dtex/2) |
(1400dtex/3) |
(1870dtex/2) |
(2100dtex/2) |
||||
1 |
Ave Breaking strength (min) |
N/end |
68 |
132.3 |
205.8 |
305 |
269.5 |
305 |
|
2 |
Elongation at certain load |
% |
11.5+1.0 (44.1 N) |
9.5+1.0 (44.1 N) |
9.5+1.0 (66.6 N) |
9.5+1.0 (100 N) |
9.5+1.0 (88.2 N) |
9.5+1.0 (100 N) |
|
3 |
Adhesion (H-test) (min) |
N/cm |
55 |
107.8 |
137.2 |
166.6 |
156.8 |
166.6 |
|
4 |
Breaking strength CV (max) |
% |
5.0 |
5.0 |
5.0 |
5.0 |
5.0 |
5.0 |
|
5 |
Breaking elongation |
% |
22+2 |
23+2 |
23+2 |
23+2 |
23+2 |
23+2 |
|
6 |
Breaking elongation CV (max) |
% |
7.5 |
7.5 |
7.5 |
7.5 |
7.5 |
7.5 |
|
7 |
Dip pick up |
% |
4.5+1.0 |
4.5+1.0 |
4.5+1.0 |
4.5+1.0 |
4.5+1.0 |
4.5+1.0 |
|
8 |
Diameter |
mm |
0.34+0.04 |
0.55+0.04 |
0.65+0.04 |
0.78+0.04 |
0.75+0.04 |
0.78+0.04 |
|
9 |
Twist |
Single (Z) |
T/10cm |
28+1.5 |
46+1.5 |
37+1.5 |
32+2.0 |
33+1.5 |
32+2.0 |
Ply twist (S) |
-- |
46+1.5 |
37+1.5 |
32+2.0 |
33+1.5 |
32+2.0 |
|||
10 |
Hot air shrinkage 160℃×2min x 0.05CN/dtex (max) |
% |
5.0 |
6.5 |
6.5 |
6.5 |
6.5 |
6.5 |
|
Our Four Core Advantages
Premium Quality
Full Customization
Factory-Direct Pricing
Reliable Global Delivery
At WEIXIN, we've streamlined our ordering process to make it easy for wholesale buyers worldwide to purchase our premium Polyester impregnated fabric and Nylon impregnated fabric for fishing net manufacturing. Follow the simple steps below to place your order.：
| Step | Stage | Description | Timeframe | Your Action |
|---|---|---|---|---|
| 1 | Inquiry Submission | Send us your requirements for Polyester or Nylon impregnated fabric | Immediate | Complete inquiry form or email us with your specifications |
| 2 | Quotation | We provide detailed pricing based on your requirements | Within 24-48 hours | Review quote and confirm acceptance |
| 3 | Sample Approval | Samples provided for quality verification | 3-7 days for sample preparation + shipping | Test samples and confirm specifications |
| 4 | Order Confirmation | Formal order placement with agreed terms | Upon sample approval | Sign sales contract and provide order details |
| 5 | Payment | Secure payment processing | As per agreed terms | Process payment via T/T, L/C, or other agreed method |
| 6 | Production | Manufacturing of your impregnated fabrics | 15-45 days (depending on order size) | Receive production updates |
| 7 | Quality Inspection | Final QC testing before shipment | 2-3 days before completion | Optional: Third-party inspection or video conference |
| 8 | Logistics Arrangement | Shipping coordination | During final production stage | Confirm shipping method and provide documentation |
| 9 | Shipment | Goods dispatched to your port | Upon production completion | Receive shipping documents |
| 10 | Delivery & Support | Goods received and after-sales support | Varies by destination | Inspect goods upon arrival; contact us with feedback |
